LY-3080B內外圓磨床
產品類別： 內外圓磨床
產品簡介
特點本機床主要用于磨削小軸、圓套、針閥、柱塞等 的圓柱面、圓錐面，工裝方式可用、三爪卡盤、 彈簧卡頭及專用夾具實現。本機床的工作臺...
產品應用
訂購熱線 135 0285 7891
產品詳細
特點

本機床主要用于磨削小軸、圓套、針閥、柱塞等   的圓柱面、圓錐面，工裝方式可用、三爪卡盤、 彈簧卡頭及專用夾具實現。本機床的工作臺縱向移   動有液動和手動,砂輪架和頭架均可轉動,液壓系統   采用了性能良好的齒輪,附帶磨內孔功能。


技術參數


Model 型號                                                                                                                LY-3080B

Grindable diameter 可磨直徑                                                                                    Φ2~Φ80mm/Φ10~Φ60mm

Grindable length 可磨長度                                                                                         300/65mm

Center height 中心高                                                                                                 115mm

Max workpiece weight 大工件重量                                                                         10kg

Workbench speed 工作臺速度                                                                                   0.1~4(r/m）

Grinding wheel line speed 砂輪線速度                                                                       35(m/sec)

Max travel of workbench 工作臺大移動量                                                                 320mm

Workbench rotation range 工作臺轉動范圍                                                                   -3°~7°

Inner spindle speed 內圓主軸轉速                                                                                15000(r/min）

External grinding wheel size  外圓砂輪尺寸          Max Φ250*25*Φ75mm           Min Φ180*25*Φ75/20*8*20mm

Tail stock taper morse 頭尾架                                                                               NO.3

Motor total power 電機總功率                                                                                   3.16kw

Roundness(O.D/I.D) 圓度(外圓/內圓)                                                                           0.002/0.005μm(O.D/I.D )

The surface roughness(O.D/I.D)  表面粗糙度(外圓/內圓)                                            Ra0.25/0.63μm (O.D/I.D )

Machine weight 機床重量                                                                                          1000kg

Machine overall dimensions(LxWxH) 機床外型尺寸(長x寬x高)                                     1360*1240*1000mm
